WorkIQ: a 5-Agent M365 Operations Fleet

WorkIQ: a 5-Agent M365 Operations Fleet

5 Copilot Studio bots plus an MCP bridge, running my own day.

Project details

Named case study
Industry

Personal productivity (dogfooded daily)

Timeline

Production since early 2026, in continuous use

Tech Stack

Copilot Studio, Direct Line, MCP, Microsoft Graph, Claude Code

Built with
  • Microsoft Copilot Studio
  • Direct Line API
  • Model Context Protocol (MCP)
  • Microsoft Graph
  • Claude Code
  • Python

Context

WorkIQ is the agent fleet I built to run my own day. 5 specialized Microsoft Copilot Studio bots, each scoped to one M365 surface (user directory, calendar, mail, Teams, OneDrive), bridged to Claude Code through 3 Model Context Protocol servers. I use it every working day at Witivio.

It is the test track for everything I deploy at client sites. If a pattern survives me being its only user, it ships to JumpStart engagements. The advisory-only pattern in this build is the lesson I cite most often.

Challenge

The textbook design for a personal M365 agent is a monolith: one bot, broad scope, friendly natural language. It works in demos and falls apart in production. Cross-surface reasoning slows down, write actions become risky because the bot conflates contexts, and the credit bill grows for tasks that should have been free Graph reads.

I wanted 3 things at once: speed on common reads, safety on writes that touch other humans, and zero accidental sends. Off-the-shelf assistants do none of those three well together.

Approach

I split the work across 3 MCP servers with strict routing:

  • graph-m365 (free, read-only) - direct Microsoft Graph calls with a cached delegated token. Default first hop for any factual lookup: read mail, list chats, fetch calendar, search files. Costs nothing.
  • m365-write (paid, writes only) - Copilot Studio Direct Line, 5 specialized bots: user, calendar, mail, Teams, OneDrive. Used only when an action has to leave the laptop.
  • workiq (paid, synthesis) - the broad-scope Copilot for natural-language queries when Graph reads come back empty or need narrative.

The routing rule is one sentence: reads go to graph-m365 first, only escalate when synthesis or a write is actually needed. Most days, 80%+ of calls are free Graph reads. Copilot credits are spent only when they earn their cost.

Topology

Topology diagram for WorkIQ: Claude Code routes prompts across 3 MCP servers - graph-m365 (free, read-only, default first hop), m365-write (paid, 5 specialized Copilot Studio bots: user, calendar, mail, Teams, OneDrive), and workiq (paid, broad-scope synthesis). All paths converge on Microsoft Graph. Roughly 80% of traffic stays on free Graph reads.3 MCP servers, color-coded by cost. Reads go to graph-m365 first, escalate only when needed.

The advisory-only pattern

Every write action goes through the same gate: the agent proposes a draft, shows me the recipients, body, and any attachments, and waits for confirmation. Nothing leaves the laptop without a human approval in the loop. This is the single most important rule in the build.

I added it after the first week of dogfooding. The agent was correct most of the time. The exceptions were the kind a busy person would miss in a scroll: wrong recipient on a sensitive thread, French formality stripped from a German message, calendar invite to the right person at the wrong time zone. Advisory-only converted every one of those into a 5-second review.

I also enforced a default of @witivio.com recipients. Sending to an external domain requires me to type the address myself. The agent will not autocomplete it.

Outcome

  • Used every working day as my primary M365 interface. Daily reads, weekly writes.
  • ~80% of M365 traffic on free Graph reads. Copilot credits spent only on synthesis or writes that earn the cost.
  • Zero accidental sends in production thanks to the advisory-only gate. The few times the draft was wrong, the review caught it.
  • Patterns ported into client engagements. The MCP routing rule and the advisory-only gate now appear in JumpStart deliveries.

What I learned

A fleet beats a monolith for personal use

Advisory-only is non-negotiable for writes

Want to talk about it?
